Multilin SR469 - Page 182

6. COMMUNICATIONS MEMORY MAP
6-34
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
1510 Reserved
...
157F Reserved
THERMAL 1580 Curve Style 0 2 1 - FC128 0
MODEL 1581 Overload Pickup Level 101 125 1 x FLA F3 101
1582 Unbalance k Factor 0 12 1 - F1 0
1583 Cool Time Constant Running 1 1000 1 min F1 15
1584 Cool Time Constant Stopped 1 1000 1 min F1 30
1585 Hot/Cold Safe Stall Ratio 1 100 1 - F3 100
1586 RTD Biasing 0 1 1 - FC103 0
1587 RTD Bias Minimum 0 250 1
o
CF1 40
1588 RTD Bias Center Point 0 250 1
o
C F1 130
1589 RTD Bias Maximum 0 250 1
o
C F1 155
158A Thermal Capacity Alarm 0 2 1 - FC115 0
158B Thermal Capacity Alarm Relays 0 6 1 - FC113 0
158C Thermal Capacity Alarm Level 10 100 1 % used F1 75
158D Thermal Capacity Alarm Events 0 1 1 - FC103 0
158E Overload Trip Relays 0 3 1 - FC111 0
158F Reserved
...
15AE Reserved
O/L CURVE 15AF Standard Overload Curve Number 1 15 1 - F1 4
SETUP 15B0 Time to Trip at 1.01 x FLA 5 999999 1 s F10 174145
15B2 Time to Trip at 1.05 x FLA 5 999999 1 s F10 34149
15B4 Time to Trip at 1.10 x FLA 5 999999 1 s F10 16667
15B6 Time to Trip at 1.20 x FLA 5 999999 1 s F10 7954
15B8 Time to Trip at 1.30 x FLA 5 999999 1 s F10 5072
15BA Time to Trip at 1.40 x FLA 5 999999 1 s F10 3646
15BC Time to Trip at 1.50 x FLA 5 999999 1 s F10 2800
15BE Time to Trip at 1.75 x FLA 5 999999 1 s F10 1697
15C0 Time to Trip at 2.00 x FLA 5 999999 1 s F10 1166
15C2 Time to Trip at 2.25 x FLA 5 999999 1 s F10 861
15C4 Time to Trip at 2.50 x FLA 5 999999 1 s F10 666
15C6 Time to Trip at 2.75 x FLA 5 999999 1 s F10 533
15C8 Time to Trip at 3.00 x FLA 5 999999 1 s F10 437
15CA Time to Trip at 3.25 x FLA 5 999999 1 s F10 366
15CC Time to Trip at 3.50 x FLA 5 999999 1 s F10 311
15CE Time to Trip at 3.75 x FLA 5 999999 1 s F10 268
15D0 Time to Trip at 4.00 x FLA 5 999999 1 s F10 233
15D2 Time to Trip at 4.25 x FLA 5 999999 1 s F10 205
15D4 Time to Trip at 4.50 x FLA 5 999999 1 s F10 182
15D6 Time to Trip at 4.75 x FLA 5 999999 1 s F10 162
