Multilin SR469 - Page 181

6. COMMUNICATIONS MEMORY MAP
6-33
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
139E General Switch C Alarm 0 2 1 - FC115 0
139F General Switch C Alarm Relays 0 6 1 - FC113 0
13A0 General Switch C Alarm Delay 1 50000 1 s F2 50
13A1 General Switch C Alarm Events 0 1 1 - FC103 0
13A2 General Switch C Trip 0 2 1 - FC115 0
13A3 General Switch C Trip Relays 0 3 1 - FC111 0
13A4 General Switch C Trip Delay 1 50000 1 s F2 50
13A5 Reserved
...
13C5 Reserved
General 13C6 1st and 2nd char. of General Switch D Name 0 65535 1 - F22 ‘Ge’
Switch D 13C7 3rd and 4th char. of General Switch D Name 0 65535 1 - F22 ‘ne’
...
13CB 11th and 12th char. of General Switch D Name 0 65535 1 - F22 ‘ ‘
13CC General Switch D Normal State 0 1 1 - FC116 0
13CD General Switch D Block Input From Start 0 5000 1 s F1 0
13CE General Switch D Alarm 0 2 1 - FC115 0
13CF General Switch D Alarm Relays 0 6 1 - FC113 0
13D0 General Switch D Alarm Delay 1 50000 1 s F2 50
13D1 General Switch D Alarm Events 0 1 1 - FC103 0
13D2 General Switch D Trip 0 2 1 - FC115 0
13D3 General Switch D Trip Relays 0 3 1 - FC111 0
13D4 General Switch D Trip Delay 1 50000 1 s F2 50
13D5 Reserved
...
14FF Reserved
RELAY 1500 Reset Mode R1 TRIP 0 2 1 - FC117 0
RESET MODE 1501 Reset Mode R2 AUXILIARY 0 2 1 - FC117 0
1502 Reset Mode R3 AUXILIARY 0 2 1 - FC117 0
1503 Reset Mode R4 ALARM 0 2 1 - FC117 0
1504 Reserved
1505 Reset Mode R6 SERVICE 0 2 1 - FC117 0
FORCE 1506 Force R1 Output Relay 0 1 1 - FC126 0
OUTPUT 1507 Force R1 Operate Time 0 300 1 s F1 0
RELAY 1508 Force R2 Output Relay 0 1 1 - FC126 0
1509 Force R2 Operate Time 0 300 1 s F1 0
150A Force R3 Output Relay 0 1 1 - FC126 0
150B Force R3 Operate Time 0 300 1 s F1 0
150C Force R4 Output Relay 0 1 1 - FC126 0
150D Force R4 Operate Time 0 300 1 s F1 0
150E Force R5 Output Relay 0 1 1 - FC126 0
150F Force R5 Operate Time 0 300 1 s F1 0
