6. COMMUNICATIONS MEMORY MAP
6-32
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
1319 Tachometer Trip Delay 1 250 1 s F1 1
131A Reserved
...
1335 Reserved
General 1336 1st and 2nd char. of General Switch A Name 0 65535 1 - F22 ‘Ge’
Switch A 1337 3rd and 4th char. of General Switch A Name 0 65535 1 - F22 ‘ne’
...
133B 11th and 12th char. of General Switch A Name 0 65535 1 - F22 ‘ ‘
133C General Switch A Normal State 0 1 1 - FC116 0
133D General Switch A Block Input From Start 0 5000 1 s F1 0
133E General Switch A Alarm 0 2 1 - FC115 0
133F General Switch A Alarm Relays 0 6 1 - FC113 0
1340 General Switch A Alarm Delay 1 50000 1 s F2 50
1341 General Switch A Alarm Events 0 1 1 - FC103 0
1342 General Switch A Trip 0 2 1 - FC115 0
1343 General Switch A Trip Relays 0 3 1 - FC111 0
1344 General Switch A Trip Delay 1 50000 1 s F2 50
1345 Reserved
...
1365 Reserved
General 1366 1st and 2nd char. of General Switch B Name 0 65535 1 - F22 ‘Ge’
Switch B 1367 3rd and 4th char. of General Switch B Name 0 65535 1 - F22 ‘ne’
...
136B 11th and 12th char. of General Switch B Name 0 65535 1 - F22 ‘ ‘
136C General Switch B Normal State 0 1 1 - FC116 0
136D General Switch B Block Input From Start 0 5000 1 s F1 0
136E General Switch B Alarm 0 2 1 - FC115 0
136F General Switch B Alarm Relays 0 6 1 - FC113 0
1370 General Switch B Alarm Delay 1 50000 1 s F2 50
1371 General Switch B Alarm Events 0 1 1 - FC103 0
1372 General Switch B Trip 0 2 1 - FC115 0
1373 General Switch B Trip Relays 0 3 1 - FC111 0
1374 General Switch B Trip Delay 1 50000 1 s F2 50
1375 Reserved
...
1395 Reserved
General 1396 1st and 2nd char. of General Switch C Name 0 65535 1 - F22 ‘Ge’
Switch C 1397 3rd and 4th char. of General Switch C Name 0 65535 1 - F22 ‘ne’
...
139B 11th and 12th char. of General Switch C Name 0 65535 1 - F22 ‘ ‘
139C General Switch C Normal State 0 1 1 - FC116 0
139D General Switch C Block Input From Start 0 5000 1 s F1 0
