Multilin SR469 - Page 179

6. COMMUNICATIONS MEMORY MAP
6-31
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
...
12BF Reserved
Pressure 12C0 Block Pressure Switch Trip from Start 0 5000 1 s F1 0
Switch Trip 12C1 Pressure Switch Trip Relays 0 3 1 - FC111 0
12C2 Pressure Switch Trip Delay 1 1000 1 s F2 50
12C3 Reserved
...
12CF Reserved
Vibration 12D0 Vibration Switch Alarm Function 1 2 1 - FC115 2
Switch Alarm 12D1 Vibration Switch Alarm Relays 0 6 1 - FC113 0
12D2 Vibration Switch Alarm Delay 1 1000 1 s F2 50
12D3 Vibration Switch Alarm Events 0 1 1 - FC103 0
12D4 Reserved
...
12DF Reserved
Vibration 12E0 Vibration Switch Trip Relays 0 3 1 - FC111 0
Switch Trip 12E1 Vibration Switch Trip Delay 1 1000 1 s F2 50
12E2 Reserved
...
12F2 Reserved
Digital 12F3 1st and 2nd char. of Counter Units Name 0 65535 1 - F22 ‘Un’
Counter 12F4 3rd and 4th char. of Counter Units Name 0 65535 1 - F22 ‘it’
12F5 5th and 6th char. of Counter Units Name 0 65535 1 - F22 ‘s ‘
12F6 Counter Preset Value 0 1000000000 1 - F9 0
12F8 Counter Type 0 1 1 - FC114 0
12F9 Counter Alarm 0 2 1 - FC115 0
12FA Counter Alarm Relays 0 6 1 - FC113 0
12FB Counter Alarm Level 0 1000000000 1 - F9 100
12FD Counter Alarm Pickup 0 1 1 - FC130 0
12FE Counter Alarm Events 0 1 1 - FC103 0
12FF Reserved
... ...
130F Reserved
Tachometer 1310 Rated Speed 100 7200 1 RPM F1 3600
1311 Tachometer Alarm 0 2 1 - FC115 0
1312 Tachometer Alarm Relays 0 6 1 - FC113 0
1313 Tachometer Alarm Speed 5 100 1 % Rated F1 10
1314 Tachometer Alarm Delay 1 250 1 s F1 1
1315 Tachometer Alarm Events 0 1 1 - FC103 0
1316 Tachometer Trip 0 2 1 - FC115 0
1317 Tachometer Trip Relays 0 3 1 - FC111 0
1318 Tachometer Trip Speed 5 95 1 % Rated F1 10
