Multilin SR469 - Page 178

6. COMMUNICATIONS MEMORY MAP
6-30
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
123F Reserved
ASSIGNABLE 1240 Assignable Input 1 Function 0 18 1 - FC110 0
INPUTS 1241 Assignable Input 2 Function 0 18 1 - FC110 0
1242 Assignable Input 3 Function 0 18 1 - FC110 0
1243 Assignable Input 4 Function 0 18 1 - FC110 0
1244 Reserved
...
1259 Reserved
Remote 125A 1st and 2nd char. of Remote Alarm Name 0 65535 1 - F22 ‘Re’
Alarm 125B 3rd and 4th char. of Remote Alarm Name 0 65535 1 - F22 ‘mo’
...
1263 19th and 20th char. of Remote Alarm Name 0 65535 1 - F22 ‘ ‘
1264 Remote Alarm Function 1 2 1 - FC115 2
1265 Remote Alarm Relays 0 6 1 - FC113 0
1266 Remote Alarm Events 0 1 1 - FC103 0
1267 Reserved
... ...
1279 Reserved
Remote 127A 1st and 2nd char. of Remote Trip Name 0 65535 1 - F22 ‘Re’
Trip 127B 3rd and 4th char. of Remote Trip Name 0 65535 1 - F22 ‘e’
...
1283 19th and 20th char. of Remote Trip Name 0 65535 1 - F22 ‘ ’
1284 Remote Trip Relays 0 3 1 - FC111 0
1285 Reserved
...
128F Reserved
Speed Switch 1290 Speed Switch Trip Relays 0 3 1 - FC111 0
Trip 1291 Speed Switch Trip Delay 10 2500 1 s F2 50
1292 Reserved
... ...
129F Reserved
Load Shed
Trip
12A0 Load Shed Trip Relays 0 3 1 - FC111 0
12A1 Reserved
... ...
12AF Reserved
Pressure 12B0 Block Pressure Switch Alarm from Start 0 5000 1 s F1 0
Switch Alarm 12B1 Pressure Switch Alarm Function 1 2 1 - FC115 2
12B2 Pressure Switch Alarm Relays 0 6 1 - FC113 0
12B3 Pressure Switch Alarm Delay 1 1000 1 s F2 50
12B4 Pressure Switch Alarm Events 0 1 1 - FC103 0
12B5 Reserved
