6. COMMUNICATIONS MEMORY MAP
6-29
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
CURRENT 1180 Phase CT Primary 1 5001 1 A F1 5001
SENSING 1181 Motor Full Load Amps 1 5001 1 A F1 5001
1182 Ground CT Type 0 3 1 - FC104 3
1183 Ground CT Primary 1 5000 1 A F1 100
1184 Phase Differential CT Type 0 2 1 - FC105 0
1185 Phase Differential CT Primary 1 5000 1 A F1 100
1186 Enable Two Speed Motor Option 0 1 1 - FC103 0
1187 Speed Two Phase CT Primary 1 5000 1 A F1 100
1188 Speed Two Motor Full Load Amps 1 5000 1 A F1 1
1189 Reserved
...
119F Reserved
VOLTAGE 11A0 Voltage Transformer Connection Type 0 2 1 - FC106 0
SENSING 11A1 Voltage Transformer Ratio 100 30000 1 - F3 3500
11A2 Motor Nameplate Voltage 100 20000 1 V F1 4000
11A3 Enable Single VT Connection 0 1 1 - FC143 0
11A4 Reserved
...
11BF Reserved
POWER 11C0 Nominal System Frequency 0 1 1 - FC107 0
SYSTEM 11C1 System Phase Sequence 0 1 1 - FC124 0
11C2 Speed2 Phase Sequence 0 1 1 - FC124 0
11C3 Reserved
...
11C7 Reserved
SERIAL COM. 11C8 Serial Communication Control 0 1 1 - FC103 0
CONTROL 11C9 Assign Start Control Relays 0 2 1 - FC137 0
11CA Reserved
...
11CF Reserved
REDUCED 11D0 Reduced Voltage Starting 0 1 1 - FC103 0
VOLTAGE 11D1 Control Relays for Reduced Voltage Starting 0 2 1 - FC137 2
11D2 Transition On 0 2 1 - FC108 0
11D3 Reduced Voltage Start Level 25 300 1 % FLA F1 100
11D4 Reduced Voltage Start Timer 1 500 1 s F1 200
11D5 Incomplete Sequence Trip Relays 0 3 1 - FC111 0
11D6 Reserved
...
122F Reserved
STARTER 1230 Starter Status Switch 0 1 1 - FC109 0
STATUS 1231 Reserved
...
