Multilin SR469 - Page 176

6. COMMUNICATIONS MEMORY MAP
6-28
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
...
1093 39th and 40th Char of Second Scratchpad Msg 32 127 1 - F1 ‘ ‘
1094 Reserved
...
109F Reserved
10A0 1st and 2nd Char of 3rd Scratchpad Message 32 127 1 - F1 ‘Te’
10A1 3rd and 4th Char of 3rd Scratchpad Message 32 127 1 - F1 ‘xt’
...
10B3 39th and 40th Char of 3rd Scratchpad Message 32 127 1 - F1 ‘ ‘
10B4 Reserved
...
10BF Reserved
10C0 1st and 2nd Char of 4th Scratchpad Message 32 127 1 - F1 ‘Te’
10C1 3rd and 4th Char of 4th Scratchpad Message 32 127 1 - F1 ‘xt’
...
10D3 39th and 40th Char of 4th Scratchpad Message 32 127 1 - F1 ‘ ‘
10D4 Reserved
...
10DF Reserved
10E0 1st and 2nd Char of 5th Scratchpad Message 32 127 1 - F1 ‘Mu’
10E1 3rd and 4th Char of 5th Scratchpad Message 32 127 1 - F1 ‘lt’
...
10F3 39th and 40th Char of 5th Scratchpad Message 32 127 1 - F1 ‘ ‘
10F4 Reserved
...
112F Reserved
CLEAR DATA 1130 Clear Last Trip Data Prompt 0 1 1 - FC103 0
1131 Reset MWh and Mvarh Meters 0 1 1 - FC103 0
1132 Clear Peak Demand Data 0 1 1 - FC103 0
1133 Clear RTD Maximums 0 1 1 - FC103 0
1134 Clear Analog Input Min/Max Data 0 1 1 - FC103 0
1135 Clear Trip Counters 0 1 1 - FC103 0
1136 Preset Digital Counter 0 1 1 - FC103 0
1137 Clear Event Records 0 1 1 - FC103 0
1138 Reserved
...
113F Reserved
INSTAL- 1140 Reset Motor Information 0 1 1 - FC103 0
LATION 1141 Reset Starter Information 0 1 1 - FC103 0
1142 Reserved
...
117F Reserved
