6. COMMUNICATIONS MEMORY MAP
6-27
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
Setpoints (Addresses 1000 -1FFF)
PREFEREN- 1000 Default Message Cycle Time 5 100 5 s F2 20
CES 1001 Default Message Timeout 10 900 1 s F1 300
1002 Reserved
1003 Average Motor Load Calculation Period 1 90 1 min F1 15
1004 Temperature Display Units 0 1 1 - FC100 0
1005 Trace Memory Trigger Position 1 100 1 % F1 25
1006 Trace Memory Buffers 1 16 1 cycles F1 8
1007 Display Update Interval 0.1 6.0 0.1 s F2 0.4
1008 Cyclic Load Filter Interval 0 32 1 cycles F1 0
1009 Passcode (Write Only) 0 99999999 1 N/A F12 0
100B Encrypted Passcode (Read Only) N/A N/A N/A N/A F12 N/A
1008 Reserved
...
100F Reserved
RS485 1010 Slave Address 1 254 1 - F1 254
SERIAL 1011 Computer RS485 Baud Rate 0 5 1 - FC101 4
PORTS 1012 Computer RS485 Parity 0 2 1 - FC102 0
1013 Auxiliary RS485 Baud Rate 0 5 1 - FC101 4
1014 Auxiliary RS485 Parity 0 2 1 - FC102 0
1015 Reserved
...
102F Reserved
REAL TIME 1030 Date N/A N/A N/A N/A F18 N/A
CLOCK 1032 Time N/A N/A N/A N/A F19 N/A
1034 Reserved
...
103F Reserved
DEFAULT 1040 Reserved
MESSAGES ...
105F Reserved
MESSAGE 1060 1st and 2nd Char of First Scratchpad Message 32 127 1 - F1 ‘Te’
SCRATCHPAD 1061 3rd and 4th Char of First Scratchpad Message 32 127 1 - F1 ‘xt’
...
1073 39th and 40th Char of First Scratchpad Message 32 127 1 - F1 ‘ ‘
1074 Reserved
...
107F Reserved
1080 1st and 2nd Char of Second Scratchpad Mes-
sage
32 127 1 - F1 ‘Te’
1081 3rd and 4th Char of Second Scratchpad Message 32 127 1 - F1 ‘xt’
