Multilin SR469 - Page 188

6. COMMUNICATIONS MEMORY MAP
6-40
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
...
181C 7th and 8th char. of RTD #5 Name 0 65535 1 - F22 ‘ ‘
181D Reserved
...
182D Reserved
182E RTD #5 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 266
182F RTD #5 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 311
RTD #6 1830 RTD #6 Application 0 4 1 - FC121 1
1831 RTD #6 Alarm 0 2 1 - FC115 0
1832 RTD #6 Alarm Relays 0 6 1 - FC113 0
1833 RTD #6 Alarm Temperature 1 250 1
o
C F1 130
1834 RTD #6 Alarm Events 0 1 1 - FC103 0
1835 RTD #6 Trip 0 2 1 - FC115 0
1836 RTD #6 Trip Voting 1 12 1 - FC122 6
1837 RTD #6 Trip Relays 0 3 1 - FC111 0
1838 RTD #6 Trip Temperature 1 250 1
o
C F1 155
1839 1st and 2nd char. of RTD #6 Name 0 65535 1 - F22 ‘ ‘
...
183C 7th and 8th char. of RTD #6 Name 0 65535 1 - F22 ‘ ‘
183D Reserved
...
184D Reserved
184E RTD #6 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 266
184F RTD #6 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 311
RTD #7 1850 RTD #7 Application 0 4 1 - FC121 2
1851 RTD #7 Alarm 0 2 1 - FC115 0
1852 RTD #7 Alarm Relays 0 6 1 - FC113 0
1853 RTD #7 Alarm Temperature 1 250 1
o
CF1 80
1854 RTD #7 Alarm Events 0 1 1 - FC103 0
1855 RTD #7 Trip 0 2 1 - FC115 0
1856 RTD #7 Trip Voting 1 12 1 - FC122 7
1857 RTD #7 Trip Relays 0 3 1 - FC111 0
1858 RTD #7 Trip Temperature 1 250 1
o
CF1 90
1859 1st and 2nd char. of RTD #7 Name 0 65535 1 - F22 ‘ ‘
...
185C 7th and 8th char. of RTD #7 Name 0 65535 1 - F22 ‘ ‘
185D Reserved
...
186D Reserved
186E RTD #7 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 176
186F RTD #7 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 194
RTD #8 1870 RTD #8 Application 0 4 1 - FC121 2
