Multilin SR469 - Page 189

6. COMMUNICATIONS MEMORY MAP
6-41
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
1871 RTD #8 Alarm 0 2 1 - FC115 0
1872 RTD #8 Alarm Relays 0 6 1 - FC113 0
1873 RTD #8 Alarm Temperature 1 250 1
o
CF1 80
1874 RTD #8 Alarm Events 0 1 1 - FC103 0
1875 RTD #8 Trip 0 2 1 - FC115 0
1876 RTD #8 Trip Voting 1 12 1 - FC122 8
1877 RTD #8 Trip Relays 0 3 1 - FC111 0
1878 RTD #8 Trip Temperature 1 250 1
o
CF1 90
1879 1st and 2nd char. of RTD #8 Name 0 65535 1 - F22 ‘ ‘
...
187C 7th and 8th char. of RTD #8 Name 0 65535 1 - F22 ‘ ‘
187D Reserved
...
188D Reserved
188E RTD #8 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 176
188F RTD #8 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 194
RTD #9 1890 RTD #9 Application 0 4 1 - FC121 2
1891 RTD #9 Alarm 0 2 1 - FC115 0
1892 RTD #9 Alarm Relays 0 6 1 - FC113 0
1893 RTD #9 Alarm Temperature 1 250 1
o
CF1 80
1894 RTD #9 Alarm Events 0 1 1 - FC103 0
1895 RTD #9 Trip 0 2 1 - FC115 0
1896 RTD #9 Trip Voting 1 12 1 - FC122 9
1897 RTD #9 Trip Relays 0 3 1 - FC111 0
1898 RTD #9 Trip Temperature 1 250 1
o
CF1 90
1899 1st and 2nd char. of RTD #9 Name 0 65535 1 - F22 ‘ ‘
...
189C 7th and 8th char. of RTD #9 Name 0 65535 1 - F22 ‘ ‘
189D Reserved
...
18AD Reserved
18AE RTD #9 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 176
18AF RTD #9 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 194
RTD #10 18B0 RTD #10 Application 0 4 1 - FC121 2
18B1 RTD #10 Alarm 0 2 1 - FC115 0
18B2 RTD #10 Alarm Relays 0 6 1 - FC113 0
18B3 RTD #10 Alarm Temperature 1 250 1
o
CF1 80
18B4 RTD #10 Alarm Events 0 1 1 - FC103 0
18B5 RTD #10 Trip 0 2 1 - FC115 0
18B6 RTD #10 Trip Voting 1 12 1 - FC122 10
18B7 RTD #10 Trip Relays 0 3 1 - FC111 0
18B8 RTD #10 Trip Temperature 1 250 1
o
CF1 90
