Multilin SR469 - Page 190

6. COMMUNICATIONS MEMORY MAP
6-42
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
18B9 1st and 2nd char. of RTD #10 Name 0 65535 1 - F22 ‘ ‘
...
18BC 7th and 8th char. of RTD #10 Name 0 65535 1 - F22 ‘ ‘
18BD Reserved
...
18CD Reserved
18CE RTD #10 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 176
18CF RTD #10 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 194
RTD #11 18D0 RTD #11 Application 0 4 1 - FC121 4
18D1 RTD #11 Alarm 0 2 1 - FC115 0
18D2 RTD #11 Alarm Relays 0 6 1 - FC113 0
18D3 RTD #11 Alarm Temperature 1 250 1
o
CF1 80
18D4 RTD #11 Alarm Events 0 1 1 - FC103 0
18D5 RTD #11 Trip 0 2 1 - FC115 0
18D6 RTD #11 Trip Voting 1 12 1 - FC122 11
18D7 RTD #11 Trip Relays 0 3 1 - FC111 0
18D8 RTD #11 Trip Temperature 1 250 1
o
CF1 90
18D9 1st and 2nd char. of RTD #11 Name 0 65535 1 - F22 ‘ ‘
...
18DC 7th and 8th char. of RTD #11 Name 0 65535 1 - F22 ‘ ‘
18DD Reserved
...
18ED Reserved
18EE RTD #11 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 176
18EF RTD #11 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 194
RTD #12 18F0 RTD #12 Application 0 4 1 - FC121 3
18F1 RTD #12 Alarm 0 2 1 - FC115 0
18F2 RTD #12 Alarm Relays 0 6 1 - FC113 0
18F3 RTD #12 Alarm Temperature 1 250 1
o
CF1 60
18F4 RTD #12 Alarm Events 0 1 1 - FC103 0
18F5 RTD #12 Trip 0 2 1 - FC115 0
18F6 RTD #12 Trip Voting 1 12 1 - FC122 12
18F7 RTD #12 Trip Relays 0 3 1 - FC111 0
18F8 RTD #12 Trip Temperature 1 250 1
o
CF1 80
18F9 1st and 2nd char. of RTD #12 Name 0 65535 1 - F22 ‘ ‘
...
18FC 7th and 8th char. of RTD #12 Name 0 65535 1 - F22 ‘ ‘
18FD Reserved
...
190D Reserved
190E RTD #12 Alarm Temperature (in Fahrenheit) 34 482 1
o
F F1 140
190F RTD #12 Trip Temperature (in Fahrenheit) 34 482 1
o
F F1 176
