6. COMMUNICATIONS MEMORY MAP
6-43
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
OPEN 1910 Open RTD Sensor Alarm 0 2 1 - FC115 0
RTD 1911 Open RTD Sensor Alarm Relays 0 6 1 - FC113 0
SENSOR 1912 Open RTD Sensor Alarm Events 0 1 1 - FC103 0
1913 Reserved
...
191F Reserved
RTD 1920 RTD Open / Low Temp Alarm 0 2 1 - FC115 0
SHORT/LOW 1921 RTD Open / Low Temp Alarm Relays 0 6 1 - FC113 0
TEMP 1922 RTD Open / Low Temp Alarm Events 0 1 1 - FC103 0
1923 Reserved
... ...
192F Reserved
RTD HIGH 1930 RTD #1 Hi Alarm 0 2 1 - FC115 0
ALARMS 1931 RTD #1 Hi Alarm Relays 0 6 1 - FC113 0
1932 RTD #1 Hi Alarm Level 1 250 1 °C F1 130
1933 Reserved
1934 RTD #2 Hi Alarm 0 2 1 - FC115 0
1935 RTD #2 Hi Alarm Relays 0 6 1 - FC113 0
1936 RTD #2 Hi Alarm Level 1 250 1 °C F1 130
1937 Reserved
1938 RTD #3 Hi Alarm 0 2 1 - FC115 0
1939 RTD #3 Hi Alarm Relays 0 6 1 - FC113 0
193A RTD #3 Hi Alarm Level 1 250 1 °C F1 130
193B Reserved
193C RTD #4 Hi Alarm 0 2 1 - FC115 0
193D RTD #4 Hi Alarm Relays 0 6 1 - FC113 0
193E RTD #4 Hi Alarm Level 1 250 1 °C F1 130
193F Reserved
1940 RTD #5 Hi Alarm 0 2 1 - FC115 0
1941 RTD #5 Hi Alarm Relays 0 6 1 - FC113 0
1942 RTD #5 Hi Alarm Level 1 250 1 °C F1 130
1943 Reserved
1944 RTD #6 Hi Alarm 0 2 1 - FC115 0
1945 RTD #6 Hi Alarm Relays 0 6 1 - FC113 0
1946 RTD #6 Hi Alarm Level 1 250 1 °C F1 130
1947 Reserved
1948 RTD #7 Hi Alarm 0 2 1 - FC115 0
1949 RTD #7 Hi Alarm Relays 0 6 1 - FC113 0
194A RTD #7 Hi Alarm Level 1 250 1 °C F1 80
194B Reserved
194C RTD #8 Hi Alarm 0 2 1 - FC115 0
194D RTD #8 Hi Alarm Relays 0 6 1 - FC113 0
