6. COMMUNICATIONS MEMORY MAP
6-44
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
194E RTD #8 Hi Alarm Level 1 250 1 °C F1 80
194F Reserved
1950 RTD #9 Hi Alarm 0 2 1 - FC115 0
1951 RTD #9 Hi Alarm Relays 0 6 1 - FC113 0
1952 RTD #9 Hi Alarm Level 1 250 1 °C F1 80
1953 Reserved
1954 RTD #10 Hi Alarm 0 2 1 - FC115 0
1955 RTD #10 Hi Alarm Relays 0 6 1 - FC113 0
1956 RTD #10 Hi Alarm Level 1 250 1 °C F1 80
1957 Reserved
1958 RTD #11 Hi Alarm 0 2 1 - FC115 0
1959 RTD #11 Hi Alarm Relays 0 6 1 - FC113 0
195A RTD #11 Hi Alarm Level 1 250 1 °C F1 80
195B Reserved
195C RTD #12 Hi Alarm 0 2 1 - FC115 0
195D RTD #12 Hi Alarm Relays 0 6 1 - FC113 0
195E RTD #12 Hi Alarm Level 1 250 1 °C F1 60
195F Reserved
UNDER- 1960 Undervoltage Active Only If Bus Energized 0 1 1 - FC103 0
VOLTAGE 1961 Undervoltage Alarm 0 2 1 - FC115 0
1962 Undervoltage Alarm Relays 0 6 1 - FC113 0
1963 Undervoltage Alarm Pickup 60 99 1 x Rated F3 85
1964 Starting Undervoltage Alarm Pickup 60 100
1
1 x Rated F3 85
1965 Undervoltage Alarm Delay 0 600 1 s F2 30
1966 Undervoltage Alarm Events 0 1 1 - FC103 0
1967 Undervoltage Trip 0 2 1 - FC115 0
1968 Undervoltage Trip Relays 0 3 1 - FC111 0
1969 Undervoltage Trip Pickup 60 99 1 x Rated F3 80
196A Starting Undervoltage Trip Pickup 60 100
1
1 x Rated F3 80
196B Undervoltage Trip Delay 0 600 1 s F2 30
196C Reserved
...
197F Reserved
OVER- 1980 Overvoltage Alarm 0 2 1 - FC115 0
VOLTAGE 1981 Overvoltage Relays 0 6 1 - FC113 0
1982 Overvoltage Alarm Pickup 101 120 1 x Rated F3 105
1983 Overvoltage Alarm Delay 5 600 1 s F2 30
1984 Overvoltage Alarm Events 0 1 1 - FC103 0
1985 Overvoltage Trip 0 2 1 - FC115 0
1986 Overvoltage Trip Relays 0 3 1 - FC111 0
1987 Overvoltage Trip Pickup 101 120 1 x Rated F3 110
1988 Overvoltage Trip Delay 5 600 1 s F2 30
