Multilin SR469 - Page 193

6. COMMUNICATIONS MEMORY MAP
6-45
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
1989 Reserved
...
199F Reserved
PHASE 19A0 Voltage Phase Reversal Trip 0 2 1 - FC115 0
REVERSAL 19A1 Voltage Phase Reversal Trip Relays 0 3 1 - FC111 0
19A2 Reserved
...
19AF Reserved
VOLTAGE 19B0 Voltage Frequency Alarm 0 2 1 - FC115 0
FREQUENCY 19B1 Voltage Frequency Alarm Relays 0 6 1 - FC113 0
19B2 Overfrequency Alarm Level 2501 7000 1 Hz F3 6050
19B3 Underfrequency Alarm Level 2000 6000 1 Hz F3 5950
19B4 Voltage Frequency Alarm Delay 0 600 1 s F2 10
19B5 Voltage Frequency Alarm Events 0 1 1 - FC103 0
19B6 Voltage Frequency Trip 0 2 1 - FC115 0
19B7 Voltage Frequency Trip Relays 0 3 1 - FC111 0
19B8 Overfrequency Trip Level 2501 7000 1 Hz F3 6050
19B9 Underfrequency Trip Level 2000 6000 1 Hz F3 5950
19BA Voltage Frequency Trip Delay 0 600 1 s F2 10
19BB Reserved
...
19CF Reserved
POWER 19D0 Block Power Factor Element from Start 0 5000 1 s F1 1
FACTOR 19D1 Power Factor Alarm 0 2 1 - FC115 0
19D2 Power Factor Alarm Relays 0 6 1 - FC113 0
19D3 Power Factor Lead Alarm Level 5 100 1 - F3 100
19D4 Power Factor Lag Alarm Level 5 100 1 - F3 100
19D5 Power Factor Alarm Delay 2 300 1 s F1 10
19D6 Power Factor Alarm Events 0 1 1 - FC103 0
19D7 Power Factor Trip 0 2 1 - FC115 0
19D8 Power Factor Trip Relays 0 3 1 - FC111 0
19D9 Power Factor Lead Trip Level 5 100 1 - F3 100
19DA Power Factor Lag Trip Level 5 100 1 - F3 100
19DB Power Factor Trip Delay 2 300 1 s F1 10
19DC Reserved
...
19EF Reserved
REACTIVE 19F0 Block kvar Element from Start 0 5000 1 s F1 1
POWER 19F1 Reactive Power Alarm 0 2 1 - FC115 0
19F2 Reactive Power Alarm Relays 0 6 1 - FC113 0
19F3 Positive Reactive Power Alarm Level 1 25000 1 kvar F1 10
19F4 Negative Reactive Power Alarm Level 1 25000 1 kvar F1 10
