6. COMMUNICATIONS MEMORY MAP
6-48
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
DEMAND 1AF1 kvar Demand Alarm 0 2 1 - FC115 0
1AF2 kvar Demand Alarm Relays 0 6 1 - FC113 0
1AF3 kvar Demand Alarm Level 1 50000 1 kvar F1 100
1AF4 kvar Demand Alarm Events 0 1 1 - FC103 0
1AF5 Reserved
...
1AFF Reserved
kVA 1B00 kVA Demand Period 5 90 1 min F1 15
DEMAND 1B01 kVA Demand Alarm 0 2 1 - FC115 0
1B02 kVA Demand Alarm Relays 0 6 1 - FC113 0
1B03 kVA Demand Alarm Level 1 50000 1 kVA F1 100
1B04 kVA Demand Alarm Events 0 1 1 - FC103 0
1B05 Reserved
... ...
1B0F Reserved
PULSE 1B10 Positive kWh Pulse Output Relay 0 3 1 - FC144 0
OUTPUT 1B11 Positive kWh Pulse Output Interval 1 50000 1 kWh F1 1
1B12 Positive kvarh Pulse Output Relay 0 3 1 - FC144 0
1B13 Positive kvarh Pulse Output Interval 1 50000 1 kvarh F1 1
1B14 Negative kvarh Pulse Output Relay 0 3 1 - FC144 0
1B15 Negative kvarh Pulse Output Interval 1 50000 1 kvarh F1 1
1B16 Running Time Pulse Relay 0 3 1 - FC144 0
1B17 Running Time Pulse Interval 1 50000 1 sec F1 0
1B18 Reserved
...
1B3F Reserved
ANALOG 1B40 Analog Output 1 Selection 0 46 1 - FC127 0
OUTPUTS 1B41 Analog Output 2 Selection 0 46 1 - FC127 0
1B42 Analog Output 3 Selection 0 46 1 - FC127 0
1B43 Analog Output 4 Selection 0 46 1 - FC127 0
1B44 Phase A Current Minimum 0 100000 1 A F9 0
1B46 Phase A Current Maximum 0 100000 1 A F9 100
1B48 Phase B Current Minimum 0 100000 1 A F9 0
1B4A Phase B Current Maximum 0 100000 1 A F9 100
1B4C Phase C Current Minimum 0 100000 1 A F9 0
1B4E Phase C Current Maximum 0 100000 1 A F9 100
1B50 Average Phase Current Minimum 0 100000 1 A F9 0
1B52 Average Phase Current Maximum 0 100000 1 A F9 100
1B54 AB Line Voltage Minimum 50 20000 1 V F1 3200
1B55 AB Line Voltage Maximum 50 20000 1 V F1 4500
1B56 BC Line Voltage Minimum 50 20000 1 V F1 3200
1B57 BC Line Voltage Maximum 50 20000 1 V F1 4500
