Multilin SR469 - Page 195

6. COMMUNICATIONS MEMORY MAP
6-47
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
OVERTORQUE
1A40 Overtorque Alarm 0 2 1 - FC115 0
SETUP
1A41 Overtorque Alarm Relays 0 6 1 - FC113 0
1A42 Overtorque Alarm Level 10 9999999 1 Nm/ftlb F2 40000
1A44 Overtorque Alarm Delay 2 300 1 s F2 10
1A45 Overtorque Alarm Events 0 1 1 - FC103 0
1A46 Reserved
...
1A7F Reserved
TRIP 1A80 Trip Counter Alarm 0 2 1 - FC115 0
COUNTER 1A81 Trip Counter Alarm Relays 0 6 1 - FC113 0
1A82 Trip Counter Alarm Level 1 50000 1 - F1 2
5
1A83 Trip Counter Alarm Events 0 1 1 - FC103 0
1A84 Reserved
...
1A8F Reserved
STARTER 1A90 Starter Failure Alarm 0 2 1 - FC115 0
FAILURE 1A91 Starter Type 0 1 1 - FC125 0
1A92 Starter Failure Alarm Relays 0 6 1 - FC113 0
1A93 Starter Failure Alarm Delay 10 1000 10 ms F1 100
1A94 Supervision of Trip Coil 0 2 1 - FC142 0
1A95 Starter Failure Alarm Events 0 1 1 - FC103 0
1A96 Reserved
...
1ACF Reserved
CURRENT 1AD0 Current Demand Period 5 90 1 min F1 15
DEMAND 1AD1 Current Demand Alarm 0 2 1 - FC115 0
1AD2 Current Demand Alarm Relays 0 6 1 - FC113 0
1AD3 Current Demand Alarm Level 10 100000 1 A F9 100
1AD5 Current Demand Alarm Events 0 1 1 - FC103 0
1AD6 Reserved
...
1ADF Reserved
kW 1AE0 kW Demand Period 5 90 1 min F1 15
DEMAND 1AE1 kW Demand Alarm 0 2 1 - FC115 0
1AE2 kW Demand Alarm Relays 0 6 1 - FC113 0
1AE3 kW Demand Alarm Level 1 50000 1 kW F1 100
1AE4 kW Demand Alarm Events 0 1 1 - FC103 0
1AE5 Reserved
...
1AEF Reserved
kvar 1AF0 kvar Demand Period 5 90 1 min F1 15
