Multilin SR469 - Page 199

6. COMMUNICATIONS MEMORY MAP
6-51
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
1BD4 Hottest Stator RTD Minimum (in Fahrenheit) -58 482 1
o
FF4 32
1BD5 Hottest Stator RTD Maximum (in Fahrenheit) -58 482 1
o
F F4 392
1BD6 Hottest Bearing RTD Minimum (in Fahrenheit) -58 482 1
o
FF4 32
1BC7 Hottest Bearing RTD Maximum (in Fahrenheit) -58 482 1
o
F F4 392
1BD8 Hottest Ambient RTD Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BD9 Hottest Ambient RTD Maximum (in Fahrenheit) -58 482 1
o
F F4 140
1BDA RTD #1 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BDB RTD #1 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BDC RTD #2 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BDD RTD #2 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BDE RTD #3 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BDF RTD #3 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BE0 RTD #4 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BE1 RTD #4 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BE2 RTD #5 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BE3 RTD #5 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BE4 RTD #6 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BE5 RTD #6 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BE6 RTD #7 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BE7 RTD #7 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BE8 RTD #8 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BE9 RTD #8 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BEA RTD #9 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BEB RTD #9 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BEC RTD #10 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BED RTD #10 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BEE RTD #11 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BEF RTD #11 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BF0 RTD #12 Minimum (in Fahrenheit) -58 482 1
o
FF4 -57
1BF1 RTD #12 Maximum (in Fahrenheit) -58 482 1
o
F F4 482
1BF2 Reserved
... ...
1BF7 Reserved
1BF8 Analog Input Diff 1-2 Minimum -50000 50000 1 - F12 0
1BFA Analog Input Diff 1-2 Maximum -50000 50000 1 - F12 100
1BFC Analog Input Diff 3-4 Minimum -50000 50000 1 - F12 0
1BFE Analog Input Diff 3-4 Maximum -50000 50000 1 - F12 100
1C00 Reserved
...
1C0A Reserved
ANALOG 1C0B Analog Input 1 Setup 0 3 1 - FC129 0
INPUT 1 1C0C Reserved
