6. COMMUNICATIONS MEMORY MAP
6-52
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
...
1C0F Reserved
1C10 1st and 2nd char. of Analog Input 1 Units 0 65535 1 - F22 ‘Un’
...
1C12 5th and 6th char. of Analog Input 1 Units 0 65535 1 - F22 ‘ ’
1C13 Analog Input 1 Minimum -50000 50000 1 - F12 0
1C15 Analog Input 1 Maximum -50000 50000 1 - F12 100
1C17 Block Analog Input 1 From Start 0 5000 1 s F1 0
1C18 Analog Input 1 Alarm 0 2 1 - FC115 0
1C19 Analog Input 1 Alarm Relays 0 6 1 - FC113 0
1C1A Analog Input 1 Alarm Level -50000 50000 1 - F12 10
1C1C Analog Input 1 Alarm Pickup 0 1 1 - FC130 0
1C1D Analog Input 1 Alarm Delay 1 3000 1 s F2 1
1C1E Analog Input 1 Alarm Events 0 1 1 - FC103 0
1C1F Analog Input 1 Trip 0 2 1 - FC115 0
1C20 Analog Input 1 Trip Relays 0 3 1 - FC111 0
1C21 Analog Input 1 Trip Level -50000 50000 1 - F12 20
1C23 Analog Input 1 Trip Pickup 0 1 1 - FC130 0
1C24 Analog Input 1 Trip Delay 1 3000 1 s F2 1
1C25 1st and 2nd char. of Analog Input 1 Name 0 65535 1 - F22 ‘An’
...
1C2A 11th and 12th char. of Analog Input 1 Name 0 65535 1 - F22 ‘ ‘
1C2B Reserved
...
1C4A Reserved
ANALOG 1C4B Analog Input 2 Setup 0 3 1 - FC129 0
INPUT 2 1C4C Reserved
...
1C4F Reserved
1C50 1st and 2nd char. of Analog Input 2 Units 0 65535 1 - F22 ‘Un’
...
1C52 5th and 6th char. of Analog Input 2 Units 0 65535 1 - F22 ‘ ’
1C53 Analog Input 2 Minimum -50000 50000 1 - F12 0
1C55 Analog Input 2 Maximum -50000 50000 1 - F12 100
1C57 Block Analog Input 2 From Start 0 5000 1 s F1 0
1C58 Analog Input 2 Alarm 0 2 1 - FC115 0
1C59 Analog Input 2 Alarm Relays 0 6 1 - FC113 0
1C5A Analog Input 2 Alarm Level -50000 50000 1 - F12 10
1C5C Analog Input 2 Alarm Pickup 0 1 1 - FC130 0
1C5D Analog Input 2 Alarm Delay 1 3000 1 s F2 1
1C5E Analog Input 2 Alarm Events 0 1 1 - FC103 0
1C5F Analog Input 2 Trip 0 2 1 - FC115 0
