Multilin SR469 - Page 201

6. COMMUNICATIONS MEMORY MAP
6-53
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
1C60 Analog Input 2 Trip Relays 0 3 1 - FC111 0
1C61 Analog Input 2 Trip Level -50000 50000 1 - F12 20
1C63 Analog Input 2 Trip Pickup 0 1 1 - FC130 0
1C64 Analog Input 2 Trip Delay 1 3000 1 s F2 1
1C65 1st and 2nd char. of Analog Input 2 Name 0 65535 1 - F22 ‘An’
...
1C6A 11th and 12th char. of Analog Input 2 Name 0 65535 1 - F22 ‘ ‘
1C6B Reserved
...
1C8A Reserved
ANALOG 1C8B Analog Input 3 Setup 0 3 1 - FC129 0
INPUT 3 1C8C Reserved
...
1C8F Reserved
1C90 1st and 2nd char. of Analog Input 3 Units 0 65535 1 - F22 ‘Un’
...
1C92 5th and 6th char. of Analog Input 3 Units 0 65535 1 - F22 ‘ ‘
1C93 Analog Input 3 Minimum -50000 50000 1 - F12 0
1C95 Analog Input 3 Maximum -50000 50000 1 - F12 100
1C97 Block Analog Input 3 From Start 0 5000 1 s F1 0
1C98 Analog Input 3 Alarm 0 2 1 - FC115 0
1C99 Analog Input 3 Alarm Relays 0 6 1 - FC113 0
1C9A Analog Input 3 Alarm Level -50000 50000 1 - F12 10
1C9C Analog Input 3 Alarm Pickup 0 1 1 - FC130 0
1C9D Analog Input 3 Alarm Delay 1 3000 1 s F2 1
1C9E Analog Input 3 Alarm Events 0 1 1 - FC103 0
1C9F Analog Input 3 Trip 0 2 1 - FC115 0
1CA0 Analog Input 3 Trip Relays 0 3 1 - FC111 0
1CA1 Analog Input 3 Trip Level -50000 50000 1 - F12 20
1CA3 Analog Input 3 Trip Pickup 0 1 1 - FC130 0
1CA4 Analog Input 3 Trip Delay 1 3000 1 s F2 1
1CA5 1st and 2nd char. of Analog Input 3 Name 0 65535 1 - F22 ‘An’
...
1CAA 11th and 12th char. of Analog Input 3 Name 0 65535 1 - F22 ‘ ‘
1CAB Reserved
...
1CCA Reserved
ANALOG 1CCB Analog Input 4 Setup 0 3 1 - FC129 0
INPUT 4 1CCC Reserved
...
1CCF Reserved
1CD0 1st and 2nd char. of Analog Input 4 Units 0 65535 1 - F22 ‘Un’
