6. COMMUNICATIONS MEMORY MAP
6-54
GROUP ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
...
1CD2 5th and 6th char. of Analog Input 4 Units 0 65535 1 - F22 ‘ ’
1CD3 Analog Input 4 Minimum -50000 50000 1 - F12 0
1CD5 Analog Input 4 Maximum -50000 50000 1 - F12 100
1CD7 Block Analog Input 4 From Start 0 5000 1 s F1 0
1CD8 Analog Input 4 Alarm 0 2 1 - FC115 0
1CD9 Analog Input 4 Alarm Relays 0 6 1 - FC113 0
1CDA Analog Input 4 Alarm Level -50000 50000 1 - F12 10
1CDC Analog Input 4 Alarm Pickup 0 1 1 - FC130 0
1CDD Analog Input 4 Alarm Delay 1 3000 1 s F2 1
1CDE Analog Input 4 Alarm Events 0 1 1 - FC103 0
1CDF Analog Input 4 Trip 0 2 1 - FC115 0
1CE0 Analog Input 4 Trip Relays 0 3 1 - FC111 0
1CE1 Analog Input 4 Trip Level -50000 50000 1 - F12 20
1CE3 Analog Input 4 Trip Pickup 0 1 1 - FC130 0
1CE4 Analog Input 4 Trip Delay 1 3000 1 s F2 1
1CE5 1st and 2nd char. of Analog Input 4 Name 0 65535 1 - F22 ‘An’
...
1CEA 11th and 12th char. of Analog Input 4 Name 0 65535 1 - F22 ‘ ‘
1CEB Reserved
..
1CFF Reserved
SIMULATION 1D00 Simulation Mode 0 3 1 - FC138 0
MODE 1D01 Pre-Fault to Fault Time Delay 0 300 1 s F1 15
Reserved
...
1D0F Reserved
PRE-FAULT 1D10 Pre-Fault Current Phase A 0 2000 1 x FLA F3 0
VALUES 1D11 Pre-Fault Current Phase B 0 2000 1 x FLA F3 0
1D12 Pre-Fault Current Phase C 0 2000 1 x FLA F3 0
1D13 Pre-Fault Ground Current 0 50000 1 A F2 0
1D14 Pre-Fault Line Voltages 0 110 1 x Rated F3 100
1D15 Pre-Fault Current Lags Voltage 0 359 1
0
F1 0
1D16 Stator RTD Pre-Fault Temperature -50 250 1
0
CF4 40
1D17 Bearing RTD Pre-Fault Temperature -50 250 1
0
CF4 40
1D18 Other RTD Pre-Fault Temperature -50 250 1
0
CF4 40
1D19 Ambient RTD Pre-Fault Temperature -50 250 1
0
CF4 40
1D1A Pre-Fault System Frequency 450 700 1 Hz F2 600
1D1B Pre-Fault Analog Input 1 0 100 1 % range F1 0
1D1C Pre-Fault Analog Input 2 0 100 1 % range F1 0
1D1D Pre-Fault Analog Input 3 0 100 1 % range F1 0
1D1E Pre-Fault Analog Input 4 0 100 1 % range F1 0
