6. COMMUNICATIONS MEMORY MAP
6-63
FORMAT
CODE
TYPE
DEFINITION
FC100 Unsigned 16 bit integer Temperature Display Units
0 Celsius
1 Fahrenheit
FC101 Unsigned 16 bit integer RS 485 Baud Rate
0 300 baud
1 1200 baud
2 2400 baud
3 4800 baud
4 9600 baud
5 19200 baud
FC102 Unsigned 16 bit integer RS 485 Parity
0 None
1Odd
2Even
FC103 Unsigned 16 bit integer Off / On or No / Yes Selection
0 Off / No
1On / Yes
FC104 Unsigned 16 bit integer Ground CT Type
0 None
1 1 A Secondary
2 5 A Secondary
3 Multilin CT 50/0.025
FC105 Unsigned 16 bit integer Differential CT Type
0 None
1 1 A Secondary
2 5 A Secondary
FC106 Unsigned 16 bit integer Voltage Transformer Connection Type
0 None
1 Open Delta
2Wye
FC107 Unsigned 16 bit integer Nominal Frequency
0 60 Hz
1 50 Hz
2 Variable
FC108 Unsigned 16 bit integer Reduced Voltage Starting Transition On
0 Current Only
1 Current or Timer
2 Current and Timer
FC109 Unsigned 16 bit integer Starter Status Switch
0 Starter Aux a
1 Starter Aux b
FC110 Unsigned 16 bit integer Assignable Input Function
0Off
1 Remote Alarm
2 Remote Trip
3 Speed Switch Trip
4 Load Shed Trip
5 Pressure Sw. Alarm
6 Pressure Switch Trip
To Next Page
