MEMORY MAP 6. COMMUNICATIONS
6-64
FORMAT
CODE
TYPE
DEFINITION
7 Vibration Sw. Alarm
8 Vibration Sw. Trip
9 Digital Counter
10 Tachometer
11 General Sw. A
12 General Sw. B
13 General Sw. C
14 General Sw. D
15 Capture Trace
16 Simulate Pre-Fault
17 Simulate Fault
18 Simulate Pre-Fault...Fault
FC111 Unsigned 16 bit integer Trip Relays
0Trip
1 Trip & Aux2
2 Trip & Aux2 & Aux3
3 Trip & Aux3
FC112 Unsigned 16 bit integer Not Defined
0
1
FC113 Unsigned 16 bit integer Alarm Relays
0Alarm
1 Alarm & Aux2
2 Alarm & Aux2 & Aux3
3 Alarm & Aux3
4Aux2
5 Aux2 & Aux3
6Aux3
FC114 Unsigned 16 bit integer Counter Type
0 Increment
1 Decrement
FC115 Unsigned 16 bit integer Alarm/Trip Type Selection
0Off
1 Latched
2 Unlatched
FC116 Unsigned 16 bit integer Switch Type
0 Normally Open
1 Normally Closed
FC117 Unsigned 16 bit integer Reset Mode
0 All Resets
1 Remote Reset Only
2 Keypad Reset Only
FC118 Unsigned 16 bit integer Short Circuit Relays
0Trip
1 Trip & Aux2
2 Trip & Aux2 & Aux3
3 Trip & Aux3
4Aux2
5 Aux2 & Aux3
6Aux3
FC119 Unsigned 16 bit integer Backup Relays
