MEMORY MAP 6. COMMUNICATIONS
6-66
FORMAT
CODE
TYPE
DEFINITION
8 Average Line Voltage
9 Phase AN Voltage
10 Phase BN Voltage
11 Phase CN Voltage
12 Average Phase Voltage
13 Hottest Stator RTD
14 Hottest Bearing RTD
15 Ambient RTD
16 RTD #1
17 RTD #2
18 RTD #3
19 RTD #4
20 RTD #5
21 RTD #6
22 RTD #7
23 RTD #8
24 RTD #9
25 RTD #10
26 RTD #11
27 RTD #12
28 Power Factor
29 Reactive Power
30 Real Power (kW)
31 Apparent Power
32 Thermal Capacity Used
33 Relay Lockout Time
34 Current Demand
35 kvar Demand
36 kW Demand
37 kVA Demand
38 Motor Load
39 Analog Input 1
40 Analog Input 2
41 Analog Input 3
42 Analog Input 4
43 Tachometer
44 MWhrs
45 Analog In Diff 1-2
46 Analog In Diff 3-4
FC128 Unsigned 16 bit integer Protection Curve Style Selection
0 Standard
1Custom
2 Voltage Dependent
FC129 Unsigned 16 bit integer Analog Input Selection
0 Disabled
1 4-20 mA
2 0-20 mA
30-1 mA
FC130 Unsigned 16 bit integer Pickup Type
0Over
1 Under
FC131 Unsigned 16 bit integer Input Switch Status
0 Open
1 Shorted
FC132 Unsigned 16 bit integer Trip Coil Supervision Status
