6. COMMUNICATIONS MEMORY MAP
6-67
FORMAT
CODE
TYPE
DEFINITION
0No Coil
1Coil
FC133 Unsigned 16 bit integer Motor Status
0 Stopped
1Starting
2 Running
3 Overloaded
4 Tripped
FC134 Unsigned 16 bit integer Cause of Event / Cause of Last Trip (up to 45)
0 No Event / No Trip To Date
1 Incomplete Sequence Trip
2 Remote Trip
3 Speed Switch Trip
4 Load Shed Trip
5 Pressure Sw. Trip
6 Vibration Sw. Trip
7 Tachometer Trip
8 General Sw. A Trip
9 General Sw. B Trip
10 General Sw. C Trip
11 General Sw. D Trip
12 Overload Trip
13 Short Circuit Trip
14 Short Circuit Backup
15 Mechanical Jam Trip
16 Undercurrent Trip
17 Current U/B Trip
18 Ground Fault Trip
19 Ground Fault Backup
20 Differential Trip
21 Acceleration Trip
22 RTD 1 Trip
23 RTD 2 Trip
24 RTD 3 Trip
25 RTD 4 Trip
26 RTD 5 Trip
27 RTD 6 Trip
28 RTD 7 Trip
29 RTD 8 Trip
30 RTD 9 Trip
31 RTD 10 Trip
32 RTD 11 Trip
33 RTD 12 Trip
34 Undervoltage Trip
35 Overvoltage Trip
36 Phase Reversal Trip
37 Volt. Frequency Trip
38 Power Factor Trip
39 Reactive Power Trip
40 Underpower Trip
41 Analog I/P 1 Trip
42 Analog I/P 2 Trip
43 Analog I/P 3 Trip
44 Analog I/P 4 Trip
45 Single Phasing Trip
48 Analog Differential 1-2 Trip
