MEMORY MAP 6. COMMUNICATIONS
6-68
FORMAT
CODE
TYPE
DEFINITION
49 Analog Differential 3-4 Trip
51 Remote Alarm
52 Pressure Sw. Alarm
53 Vibration Sw. Alarm
54 Counter Alarm
55 Tachometer Alarm
56 General Sw. A Alarm
57 General Sw. B Alarm
58 General Sw. C Alarm
59 General Sw. D Alarm
60 Thermal Model Alarm
61 Overload Alarm
62 Undercurrent Alarm
63 Current U/B Alarm
64 Ground Fault Alarm
65 RTD 1 Alarm
66 RTD 2 Alarm
67 RTD 3 Alarm
68 RTD 4 Alarm
69 RTD 5 Alarm
70 RTD 6 Alarm
71 RTD 7 Alarm
72 RTD 8 Alarm
73 RTD 9 Alarm
74 RTD 10 Alarm
75 RTD 11 Alarm
76 RTD 12 Alarm
77 Open RTD Alarm
78 Short/Low RTD Alarm
79 Undervoltage Alarm
80 Overvoltage Alarm
81 Volt. Frequency Alarm
82 Power Factor Alarm
83 Reactive Power Alarm
84 Underpower Alarm
85 Trip Counter Alarm
86 Starter Failed Alarm
87 Current Demand Alarm
88 kW Demand Alarm
89 kvar Demand Alarm
90 kVA Demand Alarm
91 Broken Rotor Bar
92 Analog I/P 1 Alarm
93 Analog I/P 2 Alarm
94 Analog I/P 3 Alarm
95 Analog I/P 4 Alarm
98 Analog Differential 1-2 Alarm
99 Analog Differential 3-4 Alarm
101 Service Alarm
102 Control Power Lost
103 Cont. Power Applied
104 Emergency Rst. Close
105 Emergency Rst. Open
106 Start While Blocked
107 Relay Not Inserted
108 Trip Coil Super.
109 Breaker Failure
