6. COMMUNICATIONS MEMORY MAP
6-69
FORMAT
CODE
TYPE
DEFINITION
110 Welded Contactor
111 Simulation Started
112 Simulation Stopped
118 Digital Trace Trigger
119 Serial Trace Trigger
120 RTD 1 High Alarm
121 RTD 2 High Alarm
122 RTD 3 High Alarm
123 RTD 4 High Alarm
124 RTD 5 High Alarm
125 RTD 6 High Alarm
126 RTD 7 High Alarm
127 RTD 8 High Alarm
128 RTD 9 High Alarm
129 RTD 10 High Alarm
130 RTD 11 High Alarm
131 RTD 12 High Alarm
FC135 Unsigned 16 bit integer Motor Speed
0 Low Speed (Speed 1)
1 High Speed (Speed 2)
FC136 Unsigned 16 bit integer Order Code
Bit 0 0 - Code P5 (5A phase CT), 1 - Code P1 (1A phase CT)
Bit 1 0 - Code HI (High Voltage Power Supply), 1 - Code LO (Low Voltage Power Sup-
ply)
Bit 2 0 - Code A20 (4-20 mA Analog Outputs), 1 - Code A1 (0-1 mA Analog Outputs)
FC137 Unsigned 16 bit integer Control Relays for Reduced Voltage Starting
0 Auxiliary 2
1 Auxiliary 2 & Auxiliary 3
2 Auxiliary 3
FC138 Unsigned 16 bit integer Simulation Mode
0Off
1 Simulate Pre-Fault
2 Simulate Fault
3 Pre-Fault to Fault
FC139 Unsigned 16 bit integer Force Operation of Relays
0 Disabled
1R1 Trip
2 R2 Auxiliary
3 R3 Auxiliary
4 R4 Alarm
5 R5 Block Start
6R6 Service
7 All Relays
8No Relays
FC140 Unsigned 16 bit integer General Status
bit 0 Relay in Service
bit 1 Active Trip Condition
bit 2 Active Alarm Condition
bit 3 Reserved
bit 4 Reserved
bit 5 Reserved
bit 6 Reserved
