MEMORY MAP 6. COMMUNICATIONS
6-70
FORMAT
CODE
TYPE
DEFINITION
bit 7 Reserved
bit 8 Motor Stopped
bit 9 Motor Starting
bit 10 Motor Running
bit 11 Overload Pickup
bit 12 Unbalance Pickup
bit 13 Ground Pickup
bit 14 Hot RTD
bit 15 Loss of Load
FC141 Unsigned 16 bit integer Output Relay Status
bit 0 R1 Trip
bit 1 R2 Auxiliary
bit 2 R3 Auxiliary
bit 3 R4 Alarm
bit 4 R5 Block Start
bit 5 R6 Service
bit 6 – bit 15 Not Used
FC142 Unsigned 16 bit integer Trip Coil Supervision Selection
0 Disabled
1 S2 Close
2 S2 Open/Close
FC143 Unsigned 16 bit integer Single VT Selection
0Off
1 AN (Wye) AB (Delta)
2 BN (Wye) BC (Delta)
3 CN (Wye) N/A (Delta)
FC144 Unsigned 16 bit integer Pulsed Output Relay Selection
0Off
1 Auxiliary2
2 Auxiliary3
3Alarm
FC145 Unsigned 16 bit integer Analog In Differential Comparison
0 % Difference
1 Absolute Difference
FC146 Unsigned 16 bit integer Analog In Differential Logic
0 1>2 (or 3>4)
1 2>1 (or 4>3)
2 1<>2 (or 3<>4)
FC147 Unsigned 16 bit integer Analog In Differential Active When
0Always
1 Start/Run
FC148 Unsigned 16 bit integer Torque Display Units
0 Newton-meter
1 Foot-pound
