4. SETPOINT PROGRAMMING S5 THERMAL MODEL
4-29
Multiples of Full Load Amps
Time to Trip in Seconds
0.1 1 10 100 1000 10000 100000
0.1 1 10 100
x1
x15
Figure 4-8 SR469 STANDARD OVERLOAD CURVES
