80
When changing the file name, go to the next
step (STEP 21).
When not changing the file name, go to
STEP 22.
STEP 21:Press BK soft key once to delete the default
file name and then enter a new file name by
using the digit keys.
STEP 22:Press or Exec soft key to start the down-
loading process. While downloading a file,
the LCD displays “Downloading...” first and
then “Saving...”.
STEP 23:After the downloading process is complete,
the display changes as follows:
The display goes back to the Download
Files screen by Exit soft key.
File Name Directory.csv (Fixed)
Code Unicode (UTF-8)
Note:
For details on character entry method, see HOW
TO INPUT CHARACTERS in chapter 4 Basic
Operation.
Note:
A maximum of 20 characters ("0-9", "A-Z", "a-z",
"*", "#", ".", "-" or "_") can be entered as a file
name.
Note:
To delete an entered character, press BK soft
key.
Note:
Be sure not to turn OFF the DT700 Series while
"Saving..." is displayed on the LCD.
Note:
When the downloading process ends in failure,
"Downloading Failed!" is displayed on the LCD.
Check to see the following and then retry.
Check Points
Actions
Download file is not
placed in the specified
directory.
Place the download file in the
specified directory.
A different file name is
specified between
DT700 Series and FTP/
TFTP server.
Set the same file name from
both DT700 Series and FTP/
TFTP server.
Incorrect IP address of
FTP/TFTP server has
been entered from the
telephone.
Set the proper IP address of
FTP/TFTP server.
The power to FTP/
TFTP server or network
equipment is OFF.
Turn on the power.
LAN cable is
disconnected.
Reconnect the cable
securely.
To Next Page
