Neoway N715-EA - Power and Control Pin Descriptions

N715-EA Hardware User Guide
Chapter 4 Module Pins
Copyright © Neoway Technology Co., Ltd. All rights reserved.
18
V
DD_P2
:
1.62 V - 1.98 V (type: 1.8 V)/2.8 V - 3.3 V (type: 3 V)
V
IH
=0.7V
DD_P2
~V
DD_P2
V
IL
=0V~0.3V
DD_P2
V
OH
=0.9V
DD_P2
~V
DD_P2
V
OL
=0V~0.1V
DD_P2
V
IH
=0.7V
DD_P2
~V
DD_P2
V
IL
=0V~0.3V
DD_P2
V
OH
=0.9V
DD_P2
~V
DD_P2
V
OL
=0V~0.1V
DD_P2
GPIO
P3: 1.8 V
V
DD_P3
: 1.7 V - 1.9 V (type: 1.8 V)
V
IH
=0.7V
DD_P3
~V
DD_P3
V
IL
=0V~0.3V
DD_P3
V
OH
=0.8V
DD_P3
~V
DD_P3
V
OL
=0V~0.2V
DD_P3
Table 4-2 Pin descriptions
Signal
Pin
I/O type
Function description
DC feature/power
domain
Remarks
Power interfaces
VBAT
36, 37
PI
Main power supply of the
module
V
min
=3.4 V, V
norm
=3.6 V,
V
max
=4.2 V
The external power supplies at least
2.5 A current to VBAT.
VBAT_SENSE
29
AI
VBAT voltage sampling pin
This pin must be connected to VBAT;
otherwise, the module cannot start up.
VDD_1P8
76
PO
1.8 V power output
V
norm
=1.8 V, I
max
= 50 mA
Used only for voltage-level translation.
Leave this pin open if unused.
GND
18, 30, 35, 38, 41, 43 - 45, 47, 73, 77 - 92
Ensure that all GND pins are
grounded.
Control interfaces
RESET_N
75
DI
Module Reset
V
ILmax
=0.5 V
Active low; used to reset the module.
This pin is connected to VBAT through
