Figure 5-41 Outgoing call service process
The following shows the process of exiting from sleep mode:
Figure 5-42 Process of existing from sleep mode
Sleep mode
MCU pulls SLEEP high
AT+ENPWRSAVE=0
End
UART enabled
Forbid sleep mode
Exits from sleep mode
Sleep mode
Initiate an outgoing
service
MCU pulls SLEEP pin
high
Enable UART and process
outgoing service
Wait till service is
processed
Complete service
processing?
End
MCU pulls SLEEP pin
low
N
Y
