USIM2_RESET
145
-
NET_MODE
L
Using the USIM2 interface and
the pins #52 to #54
simultaneously are not allowed,
that is, when the USIM2
interface is connected, you
should leave these pins open.
USIM2_DATA
146
-
SLEEP_IND
L
USIM2_CLK
147
-
NET_LIGHT
L
N715-EA provides 18 pins with multiplexing function. For more details, see section 4.2
If the signal multiplexing table is required, contact Neoway.
5.9 Other Interfaces
5.9.1 ADC
The module provides four ADC channels and their input voltage ranges from 0 V to VBAT. The ADC
interfacea support the highest precision of 12bit and it can be used for temperature detection and other
checks. For details, see Neoway_N715-EA_AT_Commands_Manual.
Signal
Pin
I/O
Function description
Remarks
ADC0
19
AI
Universal ADC interface
-
ADC1
20
AI
Universal ADC interface
ADC2
113
AI
Universal ADC interface
ADC3
114
AI
Universal ADC interface
5.9.2 WAKEUP_IN
Signal
Pin
I/O
Function description
Remarks
WAKEUP_IN
49
DI
Module wakeup
-
WAKEUP_IN the control pin of sleep mode, it needs to be used together with the AT commands. For
details, see Neoway_N715-EA_AT_Commands_Manual. In sleep mode, the module can also respond
to incoming call, SMS, and data service in time.
