ISENSE
101
AI
Charging current detection
-
-
VDRV
102
AO
Charging control
-
Used to drive the MOS transistor of
the external charging circuit, so as to
adjust the charging current.
RESERVED
97, 144
-
-
-
Used for function extension or the
function not open to users. These
RESERVE pins might have different
functions.
Leave these pins open.
