Doc. Name: NMC-PRO ׀ User Guide Ver 3.05.03 Revision: 2.2 Page: 72
Crop Management Technologies
to NO back to NO
Calibration is complete!
Calibration is complete!
Go to 9. Curve mV-% to view readings
1.
Air Inlet # – Air Inlet number corresponding with the Digital Outputs – System
Installation menu
2.
Drive F&P inlet % (Press Enter to display drop-down menu)
None - Operates as defined in the Fan&Pad Program
0% - Drives air inlet to be completely closed (0%)
100% - Drives air inlet to be completely open (100%)
3.
Calibrate position % - Define the current position of the inlet once the Drive F&P inlet
% is in the desired position
4.
Calibrate now (Press Enter to display drop-down menu) – Select YES once the desired
position has been achieved, the controller then will record the new measured values
(time/mV)
Automatic Calibration
Automatic calibration is done at a time specified by the user, once a day. If required, you can
reconfigure the NMC-Pro Climate to recalibrate the same day. Each motor can have a
different calibration time.
Note: Calibration is performed according to a system of priorities. If the motor is engaged in
a higher priority action (for example manual operations), calibration does not take place.
To enable calibration:
5. In Auto Calib select:
Off: Disables automatic calibration.
Auto: Enable automatic calibration.
o
If the current position is less than 50%, the air inlet calibrates to 0%.
o
If the current position is greater than 50%, the air inlet calibrates to
100%.
0%: The screens calibrate to 0%.
100%: The screens calibrate to100%.
6. In Auto Calib hh:mm, set the time.
Notes: While the unit is calibrating, in Status > Limitations, calibrate appears. After
calibration is completed, the measured vent position returns to its previous position.
