1
Internal Cache Active LED
2
Battery
3. Locate the blue release latch for the battery.
4. Unlatch the battery by pushing the release latch down and away from the controller canister.
1
Battery release latch
2
Battery
5. Lift up on the battery, and slide it out of the controller canister.
