Host interface card (HIC)
Thumbscrews
4. Hand-tighten the HIC thumbscrews.
Do not use a screwdriver, or you might over tighten the screws.
5. Using a #1 Phillips screwdriver, attach the HIC faceplate you removed from the original
controller canister to the new controller canister with four screws.
After you finish
Go to
Step 3: Install new controller canister (duplex)
on page 31.
30
| Maintaining E5700 Hardware
