71
GS728TS, GS728TPS, GS752TS, and GS752TPS Gigabit Smart Switches
To configure PoE trap settings:
1. If you are managing a stack of switches, select the ID of the stack member to configure
from the Unit menu.
2. Specify the percentage of the threshold power that must be consumed before a trap is sent.
3. Select the power management algorithm the switch uses to deliver power to the requesting
PDs.
• Static. The Power allocated for each port depends on the type of power threshold
configured on the port.
• Dynamic. The power consumption of each port is measured and calculated in
real-time.
4. Select the appropriate radio button to enable or disable SNMP traps for PoE.
5. Click Apply to apply the new settings to the system.
6. Click Cancel to cancel the configuration on the screen and reset the data on the screen to
the latest value of the switch.
7. Click Refresh to update the screen with the current information.
The PoE Configuration page also provides the following information:
Field Description
Firmware Version Version of the PoE controller's FW image.
Power Status Indicates whether the PoE capability is on or off.
Nominal Power Indicates the nominal amount of power the switch can provide to all ports.
Threshold Power Shows the amount of power the system can consume before the system will
not provide power to an additional port.
Consumed Power Shows the total amount of power currently being delivered to all ports.
