GS728TS, GS728TPS, GS752TS, and GS752TPS Gigabit Smart Switches
Switch Features and Defaults
Port Characteristics
Feature Sets Supported Default
Auto negotiation/static
speed/duplex
All ports Auto negotiation
Auto MDI/MDIX N/A Enabled
802.3x flow control/back pressure 1 (per system) Disabled
Port mirroring 1 Disabled
Port trunking (aggregation) 8 Pre-configured
802.1D spanning tree 1 Disabled
802.1w RSTP 1 Disabled
802.1s spanning tree 5 instances Disabled
Static 802.1Q tagging 256 VID = 1
Max member ports are:
28/52 for standalone switch
300 for 6-unit stacking switch
Learning process Supports static and dynamic MAC
entries
Dynamic learning is enabled by
default
Traffic Control
Feature Sets Supported Default
Storm control All ports Disabled
Jumbo frame All ports Disabled
Max = 9216 bytes
