268
GS728TS, GS728TPS, GS752TS, and GS752TPS Gigabit Smart Switches
Use the buttons at the bottom of the page to perform the following actions:
• To clear all the EAP counters for all ports on the switch, select the check box in the
row heading and click Clear. The button resets all statistics for all ports to default
values.
• To clear the counters for a specific port, select the check box associated with the port
and click Clear.
• Click Refresh to refresh the data on the screen and display the most current statistics.
Cable Test
Use the Cable Test page to display information about the cables connected to switch ports.
To display the Cable Test page, click the Monitoring
 Ports tab, and then click the Cable
Test link.
To perform the cable test:
1. Select one or more ports to test for cable information.
2. Click Apply to run the test.
Response/ID Frames Received Displays the number of EAP Respond ID frames that have been received
on the port.
Response Frames Received Displays the number of valid EAP Response frames received on the port.
Request/ID Frames
Transmitted
Displays the number of EAP Requested ID frames transmitted through the
port.
Request Frames Transmitted
Displays the number of EAP Request frames transmitted through the port.
Field Description
