267
GS728TS, GS728TPS, GS752TS, and GS752TPS Gigabit Smart Switches
To view EAP statistics:
1. To view statistics for a physical port, click the unit ID of the stack member with the ports
to view.
2. T
o view statistics for a Link Aggregation Group (LAG), click LAGS.
3. T
o view statistics for both physical ports and LAGs, click ALL.
4. To view statistics for a specific interface, enter the interface ID in the Go To Interface and
click Go.
The following table describes the EAP statistics displayed on the screen.
Field Description
Ports Specifies the interface which is polled for statistics.
Frames Received Displays the number of valid EAPOL frames received on the port.
Frames Transmitted Displays the number of EAPOL frames transmitted through the port.
Start Frames Received Displays the number of EAPOL Start frames received on the port.
Log off Frames Received Displays the number of EAPOL Log off frames that have been received on
the port.
Last Frame Version Displays the protocol version number attached to the most recently
received EAPOL frame.
Last Frame Source Displays the source MAC Address attached to the most recently received
EAPOL frame.
Invalid Frames Received Displays the number of unrecognized EAPOL frames received on this
port.
Length Error Frames Received Displays the number of EAPOL frames with an invalid Packet Body
Length received on this port.
