GS728TS, GS728TPS, GS752TS, and GS752TPS Gigabit Smart Switches
Slot Information
Use this page to display details of the different slots in the different units in the stack. The
page also displays information about the card types and switch models supported in the
stack.
To display the Slot Information page, click System
 Management ï€¾ï€ Slot Information. A
screen similar to the following is displayed.
Date & Time The current date and time.
System Up Time Displays the number of days, hours, and minutes since the last system restart.
Base MAC Address The universally assigned network address.
Fan Status Table
Unit ID Identifies the unit number assigned to the stack member. Up to six units are
supported in a stack, and the table contains separate columns for each possible
unit in the stack, whether the units are present or not.
Fan 1 and Fan 2 These fans remove the heat generated by the power, CPU and other chipsets,
and allow the chipsets to work normally. Fan status has three possible values:
OK, Failure, Not Present.
If the Fan 1 and Fan 2 entries for a Unit ID are blank, then no switch with that unit
number is present in the stack.
Versions Table
Unit No. Identifies the unit number assigned to the stack member.
Model Name The model name of the switch.
Boot Version The boot code version of the switch.
Software Version
The software version of the switch.
Field Description
