174
GS728TS, GS728TPS, GS752TS, and GS752TPS Gigabit Smart Switches
The Routing VLANs ARP Cache table displays the following information:
Field Description
Interface The routing interface associated with the ARP entry.
IP Address The IP address of a device on a subnet attached to one of the switch's routing
interfaces.
MAC Address The unicast MAC address for the device. The format is six two-digit hexadecimal
numbers separated by colons, for example 00:06:29:32:81:40.
Type The type of the ARP entry, which can be one of the following:
• Local - An ARP entry associated with one of the switch's routing interface's MAC
addresses
• Gateway - A dynamic ARP entry whose IP address is that of a router
• Static - An ARP entry configured by the user
• Dynamic - An ARP entry which has been learned by the router
Age Age since the entry was last refreshed in the ARP Table. The format is hh:mm:ss
Global ARP Configuration
Use the Global ARP Configuration page to display and change the configuration
parameters of the ARP table.
To display the page, click Routing  ARP, and then click the Advanced  Global ARP
Configuration link.
