172
GS728TS, GS728TPS, GS752TS, and GS752TPS Gigabit Smart Switches
ARP Cache
Use the ARP Cache page to view entries in the ARP table, a table of the remote connections
most recently seen by this switch.
To display the page, click the Routing ARP, then click the Basic ARP Cache link.
The Management VLAN ARP Cache table displays the following information:
Field Description
MAC Address Displays the MAC address of the device.
Port Shows the associated interface of the connection.
IP Address Displays the associated IP address of a device on a subnet attached to
one of the switch's existing routing interfaces.
The Routing VLANs ARP Cache table displays the following information:
Field Description
Interface The routing interface associated with the ARP entry.
IP Address Displays the associated IP address of a device on a subnet attached to
one of the switch's existing routing interfaces.
MAC Address Displays the unicast MAC address of the device.
