5. Click the Apply button.
After you save the basic settings that are shown on the page, the Day Zero Easy
Setup page no longer displays when you log in. Instead, a login window opens. After
you log in, the Dashboard page displays.
Note
6. Enter the settings that are described in the following table.
DescriptionSetting
From the menu, select the country and region in which the access point is operating.
Make sure that the country is set to the location where the device
is operating.You are responsible for complying with the local,
regional, and national regulations that are set for channels, power
levels, and frequency ranges.
Note
It might not be legal to operate the access point in a region other
than the regions listed in the menu. If your country or region is
not listed, check with your local government agency.
Note
Country/Region
From the menu, select the time zone for the country and region in which the access
point is operating.
Time Zone
Install the Access Point in Your Network and Access It for Initial Configuration
18
Insight Managed Smart Cloud Wireless Access Point WAC505 User Manual

NETGEAR WAC505 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Output current	2.5 A
Output voltage	12 V
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Internal	No
Placement	Ceiling, Wall
Product color	White
Security algorithms	802.1x RADIUS, EAP, EAP-TLS, PEAP, TTLS, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna gain level (max)	4 dBi

Weight and Dimensions

Depth	165 mm
Width	175 mm
Height	35 mm
Weight	256 g
