NETGEAR WAC505 User Manual

5. Enter the settings that are described in the following table.
DescriptionSetting
From the menu, select the country and region in which the access point is operating.
Make sure that the country is set to the location where the device
is operating.You are responsible for complying with the local,
regional, and national regulations that are set for channels, power
levels, and frequency ranges.
Note
It might not be legal to operate the access point in a region other
than the regions listed in the menu. If your country or region is
not listed, check with your local government agency.
Note
Country/Region
From the menu, select the time zone for the country and region in which the access
point is operating.
Time Zone
By default, the DHCP client of the access point allows the access point to receive
an IP address from a DHCP server (or router that functions as a DHCP server) in
your network.
To set up the access point with a static (fixed) IP address, do the following:
a. Select the Disable radio button.
Additional fields display.
b. Specify the IP address, IP subnet mask, IP address of the default gateway,
and IP address of the DNS server.
DHCP Client
As an option, enter a new system name for the access point. The name must
contain alphanumeric characters, must contain at least one alphabetical character,
cannot be longer than 15 characters, and can contain hyphens but cannot start
or end with a hyphen.
By default, the system name is Netgearxxxxxx, in which xxxxxx represents the
last six hexadecimal digits of the access point’s MAC address.
AP Name
Enter a new admin password with a minimum of 6 characters and a maximum of
32 characters.
The ideal password contains no English dictionary words and contains uppercase
and lowercase letters, numbers, and symbols. However, do not include quotation
marks (") in the password.
The admin password is the password that you use to log in to
the access point’s local browser interface. It is not the password
that you use for WiFi access.
Note
AP Login New Password
Enter exactly the same password that you entered in the AP Login New Password
field.
Confirm New Password
Install the Access Point in Your Network and Access It for Initial Configuration
22
Insight Managed Smart Cloud Wireless Access Point WAC505 User Manual

NETGEAR WAC505 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Output current	2.5 A
Output voltage	12 V
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Internal	No
Placement	Ceiling, Wall
Product color	White
Security algorithms	802.1x RADIUS, EAP, EAP-TLS, PEAP, TTLS, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna gain level (max)	4 dBi

Weight and Dimensions

Depth	165 mm
Width	175 mm
Height	35 mm
Weight	256 g
