14.2 Location and mounting
The DAQ may be situated in any protected environment.
14.3 Power Supply
This device fully relies on the Ethernet PoE supplied from the Core Module.
This unit has 1 x 100 TX PoE ports, receiving 802.3af compliant PoE @48V. The total power
budget is 12 Watts.
14.4 Connections
From the DAQ, containing the Buscoupler and (typically) multiple adaptors, there is only one
single Ethernet cable to be connected to the CM.
