NetWave NW6000 - Data Communications

Page 41/ 191
Type & Serial number
N1 N9
BCU LED1
ETHERNET (PoE) to CM
NC-CO-NO
~~~~~~~~
Serial / NMEA
ALARM
Fig. 6.4 Bridge Control Unit interfacing connections (back view)
6.5 Data communications
The Bridge Control Unit fully relies on Ethernet connections to Core Module and has to be
configured within the VDRs specified (commissioned) IP-range (refer to Network configuration).
