EDH0162En1040 – 06/99 1.24
MM4005 Introduction
12 When all necessary modifications are completed, from the screen
shown in Fig. 1.14, press the key. If modifications to any axis
have been made, the next screen will ask if you want to save the
changes (Fig. 1.15).
Fig. 1.15 — Save screen for axis modifications.
13 Press the key to save the changes and return to the main setup
menu.
NOTE
If no changes have been made, the screen in Fig. 1.15 will not appear.
14
Press to return to the main MOTOR menu.
Now, with all axes configured for the proper motion devices, we are ready
to use the motion devices.
OFF
QUIT
YES
