2.11 EDH0162En1040 – 06/99
MM4005 Local Mode
2.2.1.7 Terminator
This parameter defines the terminator to be used in communication with a
host computer or a terminal. As described in the Remote Mode section, the
controller responds to command lines, not characters. In order for a com-
mand to be acted upon, it must be followed by the terminator.
The MM4005 controller offers a choice of four command line terminators
which are combinations of line-feeds and carriage-returns: LF, CR, CR/LF
and LF/CR.
To change the existing selection from the General Setup menu, press
until the Terminator parameter appears on the display. Press
and then the key until the desired terminator is selected.
Press the key to accept the entry and return to the previous menu.
The factory default terminator is LF.
→→→→→
→→→
CMTxx — Set communication terminator.
2.2.1.8 Communication
This setting selects the communication port to be used with a host comput-
er. The MM4005 controller can use either the RS-232 or IEEE-488 interface but
only one at a time. The selection can be made only through this setup.
Default mode is RS-232-C.
To change the existing selection from the General Setup menu, press
until the Communication parameter appears on the display. Press
and then the key to select a new communication port. Press the
key to accept the entry and return to the previous menu.
→→→→→
→→→
CMMxx — Set communication mode.
QUITQUITVALID
CHANGE
MODIFY
UP
GEN.SETUP
Motor OFF
1
4
7
2
5
8
3
6
9
.
-
0
Axis 1
Axis 2
Axis 3
Axis 4
JOG
MANU PROG .
1:
2:
3:
4:
21
2.34 mm
nUcon
56
3-.35 mm6
nect
LA
HOME
Steactionlec
MOV E
.345 Deg
ed
VALID
CHANGE
MODIFY
UP
QUITQUITVALID
CHANGE
MODIFY
UP
GEN.SETUP
Motor OFF
1
4
7
2
5
8
3
6
9
.
-
0
Axis 1
Axis 2
Axis 3
Axis 4
JOG
MANU PROG .
1:
2:
3:
4:
21
2.34 mm
nUcon
56
3-.35 mm6
nect
LA
HOME
Steactionlec
MOV E
.345 Deg
ed
VALID
CHANGEMODIFY
UP
