2.13 EDH0162En1040 – 06/99
MM4005 Local Mode
→→→→→
→→→
CMBxx — Set serial communication baud rate.
2.2.1.12 XON/XOFF Mode
XON/XOFF mode synchronizes work between the transmitter and the
receiver. In this mode, XON and XOFF characters are sont automatically
generated (XOFF if the receipt buffer is almost full and risks to be erased,
XON if the receipt buffer is sufficiently emptied to receive new characters).
To change the setting, from the General Setup menu, press until
the XON/XOFF Mode appears on the display. Press and then
the key to select YES. Press the key to accept the entry and
return to the previous menu.
The factory default is NO.
→→→→→
→→→
CMXxx — Set serial communication XON/XOFF mode.
2.2.1.13 Parity
Parity must be set correctly for the RS-232-C communication to work prop-
erly. As the standard suggests, when a word length of less than 8 is used,
the parity bit can be set to Odd or Even. Both communicating devices must
use the same setting.
The possible settings are Odd, Even and None. The factory default is None.
If the RS-232-C is not used, ignore the selection by pressing the key
and advancing to the next parameter.
To change the setting, from the General Setup menu, press until
the Parity parameter appears on the display. Press and then
the key to select a new parity. Press the key to accept the
entry and return to the previous menu.
→→→→→
→→→
CMPxx — Set serial communication parity.
QUITQUITVALID
CHANGE
MODIFY
UP
GEN.SETUP
Motor OFF
